Raven RP26
  • Specification
  • Downloads

A heavy duty sweep seal for door bottoms of outward opening doors. Slotted fixing holes allow for adjustment all concealed behind a push in cover strip. The RP26 is ideal for use in conjunction with Raven threshold plates.

  • Location: Bottom of single and double, outward opening, butt hinged doors, tilt up doors or can be used as an astragal seal.
  • Min/Max Gap:5mm to 20mm (user determined).
  • Finish:Satin clear (silver), bronze anodised aluminium (15µm) or paint at extra cost
  • Fixing: Concealed screw fix. Zinc plated, cross recess head S.T. screws and cover strip supplied. Fixing holes are pre-slotted.
  • Seal: RP326. Black EPDM.
  • Sizes: Available in stock lengths.
  • Cert. GVYI.R37913
  • Fire AUS/NZ:NCC Spec. F5.5.
  • UK/EU:Approved Document E. Rated to BS EN ISO 717-1.
  • Fire AUS/NZ:NCC Spec. C3.4. AS1530.4 & AS/NZS 1905.1.
  • UK/EU:Approved Document B. BS 476 Pt. 20 & 22 (similar to BS EN 1634-1).
  • UK/EU:Approved Document B. BS EN 1634-1.
  • FRL & FRR-/120/30 and FD120.
  • SmokeNCC Spec. C3.4. AS1530.7 & BS EN 1634-3. Meets smoke leakage rates specified in AS6905 & EN 13501- 2 “Sa”, “Sm”.
  • EnergyNCC Pt. 3.12.3.3 & J3.4.

RAVEN RP26 Door Bottom Seal 1000mm

SKU WSRP26.1000.BZA

In stock, within 1 week


Bronze AnodisedClear AnodisedPainted
1000mm3000mm1250mm1500mm2000mm

Total Price

$72.50
